Electric hoists represent their own machinery, strength, and toughness, while the stage is elegant, flowing, and soft, with conflicts and collisions between the two.
What are the characteristics of common wire rope electric hoists? The wire rope electric hoist has the following characteristics:
Category : W12 Stage Electric Hoist
Get a Quote
Product Details
What are the characteristics of common wire rope electric hoists? The wire rope electric hoist has the following characteristics:
1. The design benchmark level is M4, and the design life is 10 years.
2. Compact structure and good grouping. The lifting and operating mechanisms all adopt a "three in one" driving device, which includes an electric motor, brake, and reducer.
3. Installation, adjustment and use, easy maintenance, can be connected to different forms of running cars, forming various forms of electric hoists.
4. Safe and reliable, adopting various safety protection devices and measures. The electric motor adopts thermoelectric protection to limit the temperature rise of the motor, and the winding is equipped with a bismuth metal temperature control protection device, which can prevent the motor from overheating due to overload or frequent starting;, The motor shaft head is directly milled with helical teeth as the first driving main spur gear, which changes the braking torque with the load and improves braking performance; A second brake can be installed as needed; The drum is equipped with a rope guide to prevent tangled ropes; 2.4.5 Equipped with up and down bidirectional limit devices with phase sequence protection function; Equipped with power-off limiters; Emergency stop device; Equipped with a lifting capacity limiter or a lifting capacity digital display device; The operating mechanisms are all bilateral driven and equipped with protective devices.
5. The retrieval device consists of a hook with a protective hook, a limit core steel wire rope, and a drum. The drum shell is a square bracket, which is easy to connect with various running carts. The rope guide on the drum is split, which is easy to disassemble and adjust.
