Electric hoists represent their own machinery, strength, and toughness, while the stage is elegant, flowing, and soft, with conflicts and collisions between the two.
Compact structure, small shape, light weight, suitable for operation in ultra-small space and convenient handling.
Category : V7 Stage Electric Series
Get a Quote
Product Details
Introductions:
Compact structure, small shape, light weight, suitable for operation in ultra-small space and convenient handling.
The protection grade of the whole machine is IP66, and it can work in the rain.
The hook can rotate 360 degrees and is designed to prevent decoupling.
G80 chain EN 818-7, 8 times safety factor
The clutch is integrated on the rotor shaft and adopts dry clutch friction plate. It does not slide after clutch wear to ensure safety.
Maintenance free electromagnetic braking, brake locking at the first time after power failure.
Helical gear transmission, gear grade 6, operating noises 60 dB
The lower hook lifting ring design is safer to use with shackle.
High strength special nylon chain guide ensures smooth chain operation.
Cast aluminum integrated shell and heat treatment make the fuselage firmer and reduce the weight of the fuselage.
The clutch is on the transfer shaft of the motor.
