Regarding the issue of hand chain hoist brakes
In fact, operating a chain hoist for lifting operations is a technical task. For a professional chain hoist operator, it is necessary to have rich operational knowledge and experience, understand the maintenance methods of the chain hoist, and effectively inspect and solve any problems that may occur. In fact, these are all experiences accumulated through long-term use. Below, we will mainly talk about one of the faults, the braking problem.
I believe that some operators have encountered problems with the brakes being too tight or not working properly when using a chain hoist to lift goods.
First of all, if the brake is too tight, it is mostly due to the small gap between the ratchet and the friction plate, which increases the friction force. A slight pull on the manual hoist can cause difficulty in operation, and even chain jamming. At this time, just adjust the gap distance between the ratchet and the friction plate. Moreover, brake failure is also related to the ratchet and friction plate. If the gap between them is too large, it can also cause brake failure. Just adjust the gap distance. Another issue is that the friction plate is severely worn due to long-term and frequent use, or overloading and other incorrect operating methods, resulting in the loss of friction ability and causing Huiling. At this point, new accessories need to be replaced.
From the above, it can be understood that the gap distance between the ratchet and friction plate of the chain hoist can cause problems if it is too close or too far, so it is necessary to adjust it to the appropriate distance. Also, if there is a problem with the components of the chain hoist that cannot be repaired, it is necessary to replace them with new ones in a timely manner and avoid continuing to use them to avoid accidents.
