Electric hoists represent their own machinery, strength, and toughness, while the stage is elegant, flowing, and soft, with conflicts and collisions between the two.

TAG :
lift Stage Winch|

Concert Entertainment Silent Stage Truss Motor Hoist

Time：2024-06-11

Brief Explanation :

Pre use inspection of stage electric hoist　　1. There should be no obstacles within the walking range of the operator and on the route through which heavy objects pass.

Category : W12 Stage Electric Hoist

Get a Quote

Product Details

　　Pre use inspection of stage electric hoist

　　1. There should be no obstacles within the walking range of the operator and on the route through which heavy objects pass.

　　2. The manual buttons should move correctly and agilely in the up, down, left, and right directions, and there should be no abnormal sounds from the electric motor and reducer.

　　3. The brake should be agile and reliable.

　　4. There should be no foreign objects on the running track of the electric hoist.

　　5. The action of the upper and lower limit switches should be correct.

　　6. The locking nut of the hook should be tightened.

　　7. The hook should roll flexibly in both horizontal and vertical directions.

　　8. The hook pulley should roll flexibly.

　　9. The steel wire rope should have no significant defects, be neatly arranged on the drum, have no signs of detachment from the pulley groove, and be well lubricated.

　　10. There are no abnormalities in the lifting accessories.

　　11. The working environment temperature of the electric hoist is -25~+40 ℃

　　12. Electric hoists are not suitable for use in places with corrosive gases or relative humidity greater than 85%. They cannot replace explosion-proof hoists and are not suitable for lifting molten metals or toxic, flammable, and explosive materials.

　　Understand the characteristics of stage electric hoists. When using, there are several important points to keep in mind.

　　1. Choose the right power supply voltage

　　When using a stage electric hoist on stage, the first step is to determine the operating voltage and whether it can ensure the normal operation of the stage electric hoist.

　　2. The suspension point should be sturdy and stable

　　When using the stage electric hoist, it is important to ensure that the crossbeams on the stage are sturdy and able to withstand significant impact forces. And the appearance is beautiful.

　　3. Be careful during the installation process

　　When using stage electric hoists to set up items, ensure that the commanding personnel observe carefully and promptly stop and return them to their original positions in case of deviations. Only after identifying the cause can the installation continue.

　　4. Timely maintenance should ensure

　　The good durability of the stage electric hoist has always been its characteristic. So it is applied in many stages. Timely maintenance of the stage electric hoist is fundamental to ensuring the durability of lifting products.

Stage electric hoist product details
