Electric hoists represent their own machinery, strength, and toughness, while the stage is elegant, flowing, and soft, with conflicts and collisions between the two.
G80 level lifting chains require regular inspections to prevent potential problems. Firstly, we need to check the surface of the chain for deformation, wear, cracks, or rust before use. If any issues
Category : V7 Stage Electric Series
Get a Quote
Product Details
G80 level lifting chain regular inspection
G80 level lifting chains require regular inspections to prevent potential problems. Firstly, we need to check the surface of the chain for deformation, wear, cracks, or rust before use. If any issues arise, we need to repair or promptly contact the manufacturer for replacement to ensure that the quality of the chain is not compromised before starting work.
If any jamming, abnormal noise or abnormal vibration is found during operation, the work needs to be stopped immediately and can only continue after eliminating the abnormality.
After use, we need to apply lubricating oil to the surface of the lifting chain and place it in a dry place to prevent rusting.
High quality environment increases the lifespan of lifting chains
After the maintenance or cleaning of the lifting chain is completed, if it is placed in a random place, the maintenance or cleaning effect will be greatly reduced. If you want to prolong the service life of this product, the following four conditions should be met in daily storage:
1、 The content of corrosive particles is relatively low, indicating that air pollution is not severe.
2、 The water content in the air is relatively low, that is, the air humidity is low.
3、 The direct sunlight has a shorter duration and weaker intensity.
4、 Stay away from flammable and explosive environments.
To ensure storage security, it is necessary to choose a suitable storage environment, and be sure to choose the storage environment according to the suggestions we provide, so that it can be stored well.
Precautions for lifting chains
After using the lifting chain for a period of time, it will cause wear on the sprocket. If the sprocket is severely worn, it should be replaced with a new sprocket and a new chain at the same time to ensure good meshing. You cannot just replace the chain or sprocket separately. Otherwise, it will cause poor meshing and accelerate the wear of new chains or sprockets. After the sprocket tooth surface is worn to a certain extent, it should be flipped over for use in a timely manner (referring to sprockets with adjustable surfaces). To extend the usage time.
The new chain is too long or stretched after use, making it difficult to adjust. The chain links can be removed depending on the situation, but they must be even. The chain link should pass through the back of the chain, the locking plate should be inserted outside, and the opening of the locking plate should face in the opposite direction of rotation.
The old lifting chain cannot be mixed with some new chains, otherwise it may cause impact and break the chain during transmission.
