Electric hoists represent their own machinery, strength, and toughness, while the stage is elegant, flowing, and soft, with conflicts and collisions between the two.
Firstly, a good hanging point for a chain hoist. In many cases, the use of the stage is in good venues, such as sports arenas, art centers, etc
Category : Stage Chain Hoist Series
Get a Quote
Product Details
Fixation points for stage chain hoists:
Firstly, a good hanging point for a chain hoist. In many cases, the use of the stage is in good venues, such as sports arenas, art centers, etc., where there are dedicated hanging points above. So when fixing the stage gourd, if there are these good designs, hang it directly on it to ensure a safer operation.
Secondly, track clamps. If there are no good fixing conditions, it can be fixed on the track clamp, and then the track clamp is fixed on the I-beam, so that a solid lifting point is achieved.
Thirdly, lifting straps. To lift heavy objects under the stage bracket, the lifting belt can be hung at the center of the bracket, and then the stage chain hoist can be hung on the lifting belt. However, it should be noted that the load-bearing capacity of the lifting belt must be greater than the rated load of the hoist, in order to avoid overloading.
Fourthly, the chain. If there is a sturdy location to tie the chain, the stage chain hoist hook can also be hung on a circular chain composed of chains. The load-bearing capacity of this chain must be greater than the rated load of the hoist to avoid overloading.
The above are the places where the stage gourd hook can be fixed. Another point to emphasize is that it is not recommended to directly hook the gourd hook onto the stage bracket, as this can easily cause the bracket to collapse and pose a danger.
